| SKU | AI0128 |
| Condition | Used / Inspected |
| Warranty | 30 Days |
| Categories | Bearings, Pillow Block Bearings, Power Transmission |
| Ships From | Bardstown, KY |
| Ground | UPS / FedEx |
| Express | Next Day Air Available |
| Freight | Available on Request |
| Cutoff | 2:00 PM EST Mon–Fri |
The Dodge LF-SC-103 is an intermediate duty pillow block ball bearing unit designed for reliable power transmission applications. This series 206 bearing features a 1-3/16 inch bore diameter with setscrew locking and a three-bolt base flange mounting configuration.
| Specification | Value |
|---|---|
| Brand | Dodge |
| Model/Part Number | LF-SC-103 |
| Bearing Type | Pillow Block |
| Series | 206 |
| Bore Diameter | 1-3/16 inch |
| Mounting Type | 3-Bolt Base Flange |
| Bearing Insert Type | Ball Bearing |
| Locking Device | Setscrew |
| Bolt Center-to-Center | 3.56 inch |
| Bolt Circle Diameter | 3.56 inch |
| Overall Length/Diameter | 4.44 inch |
| Overall Depth | 1.45 inch |
| Dynamic Load Rating | 4368 lbs |
| Static Load Rating | 2538 lbs |
| Maximum Speed | 6500 RPM |
| Operating Temperature | 225 to 400°F |
| Bearing Material | Steel |
| Seal Type | Nitrile Rubber |
| Housing Finish | Powder Coated |
| UPC | 782475513604 |
We warranty all items for 30 days from date of purchase.
| Brand | Dodge |
| Manufacturer | Dodge |
| Model | LF-SC-103 |
| MPN | LF-SC-103 |
| Part Number | LF-SC-103 |
| Condition | Used |
| Material | Steel |
| Weight | 3.00 |
| Mounting Type | 3-Bolt Base Flange |
| Shelf Location | A-3 |
| Country of Origin | United States |
| Unit Type | Pillow Block |
