2 in stock
| SKU | IP545838549 |
| Condition | Used / Inspected |
| Warranty | 30 Days |
| Categories | Photoelectric Sensors, Proximity Sensors, Sensing Devices |
| Ships From | Bardstown, KY |
| Ground | UPS / FedEx |
| Express | Next Day Air Available |
| Freight | Available on Request |
| Cutoff | 2:00 PM EST Mon–Fri |
| Detection method | Diffuse reflective |
|---|---|
| Detecting distance | 2-50mm (50x50mm white drawing paper) |
| Detection object | Opaque, translucent, transparent |
| Power supply | 12-24V DC±10% / Ripple 10% or less |
| Current consumption | 27mA or less |
| Output mode | NPN open collector Rating: sink current 80mA (30 VDC) or less |
| Operation mode | (See the Type table in the previous page) |
| Response time | 0.5ms or less |
| Hysteresis | Up to 10% of detecting distance |
| Light source (light wavelength) | Red LED (640nm) |
| Indicator | Operation indicator (red LED), Stability indicator (green LED) |
| Volume (VR) * | in-line sensitivity adjustment |
| Material | Case : Liquid crystalline polyester (filler: polypropylene) Lens : Acryl resin |
| Connection | Attached cable (dia. 2.8) 0.15 mm2 x 3 cores 2m (black) |
| Weight | Approx. 40g |
| Notes | * The distance between the sensor and the in-line volume for sensitivity adjustment is fixed to 300mm. |
| Accessory | Instruction manual, mounting screws, washers, nuts, screwdriver for adjustment (attached to the model whose model number ends with “V”) |
| Ambient light | 3,000 lx or less |
|---|---|
| Ambient temperature | -25 - +55C (non-freezing) |
| Ambient humidity | 35-85%RH (non-condensing) |
| Protective structure | IP64 |
| Vibration | 10 - 55 Hz / 1.5 mm double amplitude / 2 hours each in 3 direction |
| Brand | Takex |
| Manufacturer | Takex |
| Model | UM-R5TV |
| MPN | UM-R5TV |
| Condition | New |
| Weight | 1.00 |
| Voltage | 12-24V |
| Current Type | DC |
| Output Type | Open Collector |
| Sensor Type | Solid State |
| Shelf Location | Q-7 |
| Unit Type | Photoelectric Sensor |
