Banner QS18VP96AF300Q5 Photoelectric Sensor, 10-30V DC

Banner QS18VP96AF300Q5 Photoelectric Sensor, 10-30V DC Sensing Beam Visible Red LED Power DC Sensing Mode (General) Proximity Sensing Mode (Detailed) Background Suppression (Adjustable) Housing Style Rectangular Primary Housing Material ABS Input/Output Discrete Max Sensing Distance (mm) 300 Outputs PNP Power Supply/Supply Voltage 10-30 V dc Connection Pigtail QD Quick Disconnect Type M12 (Euro) Min Op. Temp. (°C) -20 Operation Light/Dark Operate Max Op. Temp. (°C) 55 Output response time (ms) 2.5 Special Feature: Intrinsically Safe No Special Feature: Remote Teach No Special Feature: Water Detection No Sensing Beam Wavelength 640 Delay at Power-up (ms) 200 Repeatability (µs) 250 Number of Pins 4 IP Rating IP67 NEMA Rating NEMA 6 Max Op. Relative Humidity [%] 95% @ 50°C Lens Material Acrylic Adjustments Mechanical Screw Barrel Diameter (mm) N/A Indicator LEDs Feature: Timing (Hold/Delay) No Feature: Encapsulated No Feature: Hazardous Area No Feature: Audible No Feature: Chemical Resistant No Feature: Quick Disconnect Yes DeviceNet No IO Link No
